Vision Systems for Dimensional QC

Our high-resolution line scan camera with 12K pixel array detects surface micro-cracks and geometric deviations as small as 5 microns at conveyor speeds up to 5 m/s. The actual detection threshold depends on lighting conditions and material reflectivity, but typical installations achieve consistent sub-10 micron sensitivity for most industrial surfaces.

The Matrix Image Processing Software Suite supports up to 16 concurrent camera feeds, processing over 200 frames per second using GPU acceleration. Each feed is analyzed independently with configurable defect classification models, and results are aggregated into a unified dashboard for real-time monitoring and statistical process control reporting.

Yes, the software suite includes built-in connectors for MES and SCADA systems via OPC UA, Modbus TCP, and REST APIs. Defect data, rejection triggers, and traceability logs are automatically pushed to your existing platform without custom middleware. On-site integration testing is part of the standard installation.

The High-Resolution Line Scan Camera Module is rated IP67, meaning it is fully protected against dust ingress and temporary immersion in water. It operates reliably in ambient temperatures from -10°C to 50°C and humidity up to 95% non-condensing. The housing is constructed from anodized aluminum with sealed optical windows to resist industrial contaminants.

The Conveyor Band Inspection System Bundle is pre-calibrated for conveyor widths up to 2 meters and speeds up to 5 m/s. On-site installation and operator training typically require two to three days. The bundle reduces setup time by approximately 70% compared to custom integrations, with most production lines resuming normal operation within the same week.
